Bodyboard Motorizado KOOTU – Potencia Extrema para Surfistas Apasionados



Lista de embalaje:

Tabla de surf x1, Batería x1, Cargador x1, Control Grip x1, Zapatos x 2, Aletas centrales * 1, Aletas laterales * 4, Herramientas de montaje y otros repuestos de tabla de surf.

Por favor, deje su dirección de correo electrónico después de comprar el tablero.

Después de recibir la placa, comuníquese con el servicio de atención al cliente para enviar el manual de funcionamiento de la placa, el vídeo y otros documentos relacionados.

La tabla de surf tiene una garantía de 1 año. En condiciones normales de uso, si la falla se debe a problemas de fabricación o del material, reemplazaremos las piezas necesarias sin cargo durante el período de garantía.

(Las piezas de desgaste y los daños provocados por un uso inadecuado no están cubiertos por la garantía)

Instrucciones de seguridad para el surf:

1. Antes de practicar surf, use casco, traje de baño y chaleco salvavidas; el surf es un deporte extremo, especialmente el surf de potencia, así que mantenga la cabeza despejada.

2, para comprender la seguridad del agua: sin objetos flotantes; profundidad del agua de al menos 80 cm; verifique si hay arrecifes, ramas, redes, peces grandes u otros factores desconocidos que afecten su seguridad;

3. Antes de utilizar la tabla de surf en el agua, consulte con el servicio de atención al cliente para enviar los documentos pertinentes de la tabla de surf.

Primero debes comprender el funcionamiento de la tabla de surf, el manual de seguridad y el tratamiento de situaciones de emergencia que puedes encontrar.

4, When surfing in shallow water, please use the “both knees” method. Please protect yourself when you start and do not go too fast;

5、When getting off the surfboard, please hold down the power switch, kneel down first and wait until everything is normal before getting off the surfboard;

6、When resting on the shore or in the water, please make sure to remove the safety key to avoid accidents;

Maintenance :

1, after surfing, should be placed in a cool and ventilated place. The battery will generate a certain temperature, let it cool down naturally. Batteries are prohibited from charging outdoors, do not overcharge, and unplug the charging plug promptly when fully charged.

(Do not expose the battery to sunlight, if the temperature is too high, the service life of the battery may be shortened and a safety hazard may occur).

2、After surfing in the sea, fresh water should be used to clean the surfboard and cooling system.

3、When surfing, you should pay attention to whether the sound of the surfboard is normal or not, when the sound is abnormal or the power drops, please stop the machine in time to check;

4、When surfing, you should pay attention to whether there is any accumulation of water in the cabin. If there is standing water timely discharged, or wipe dry can, does not affect the use. If not discharged in time, it will accelerate the aging of the product.

Precautions

1. Charge the battery:

2.Charge the battery fully before each play session, using 220 V current to charge the battery.

There are indicator lights on the charger. * Red: charging, * Green: fully charged or disconnected.

A minimum charging time of 5 hours is required to go from 0% to 100% capacity. The voltage of a fully charged battery should be 16 - 16.8V.

(Make sure to connect the connectors correctly, with the two arrows facing each other).

NOTE: The battery must be removed for charging. It is forbidden to charge the battery in the engine compartment. When not using the product, store the battery separately and do not leave it in the engine compartment.

3. Fuel Ratio

Use No. 95 gasoline (or higher) and lubricating oil. The ratio is 30:1.

4. Difficulty starting the engine.

When used for the first time. It may be difficult to start. Please open -> close -> open the carburetor handle and repeat the above action when starting the engine. Increase the intake pressure to make starting successful.

5. Do not press the start button more than 5 times in a row under any circumstances (on shore or in the water) as this may cause the starter motor and starter battery to overheat and become damaged.

6. If the engine is started on land, do not hold it for more than 30 seconds to avoid overheating the engine.

If the engine is successfully started on shore, turn off the engine promptly. If a demonstration or function test is required on land, connect a hose and supply water.

In addition, if the engine is kept started on land, the engine speed will remain high due to the absence of power load and water resistance.

Si el motor funciona a toda velocidad sin carga de potencia, esto puede provocar una “sobremarcha”: el motor seguirá funcionando sin control incluso si se quita la llave de seguridad (si esto ocurre, se debe bloquear inmediatamente la entrada del carburador para que el motor se detenga).

Por eso, si quieres probar la máxima potencia de tu tabla de surf, ¡hazlo en el agua!
